A circuit board in. A film out.
Give silk reel a KiCad board file. Get a release film of that board.
npm run reel -- board.kicad_pcbEvery frame, in your hands.
Scroll to run the film one frame at a time.
Every board, drawn to scale.
Scroll to travel it. Over the board, the pointer moves the cut.
The same file, as a film.
Two looks. One board.
Pick a style. Each film is built from the same board file.
The lit board under a camera, from bare copper to powered on.
Every part of the board set as type, in a loop.
Glasgow rev C3 · Glasgow Embedded · 0BSD · iCEBreaker © 2019 1BitSquared · CC BY-SA 4.0
One command. Any board.
Change a word and the film below follows. Copy the line to render it on your machine.
npm run reel --
1920 px1080 px
